Triumph Trident 800
Find technical data, prices and reviews.
Key Specification Triumph Trident 800 2026
Engine and Drive Train
| Engine type | In line |
|---|---|
| Bore | 78 mm |
| Stroke | 55.7 mm |
| Engine power | 115 HP |
| Rpm at Max. Power | 10750 rpm |
| Torque | 84 Nm |
| Rpm at Torque | 8500 rpm |
| Compression Ratio | 13.2 |
| Fuel system | Injection |
| Starter | Electric |
| Clutch Type | Multiplate in oil-bath, Antihopping, , |
| Transmission | Chain |
| Transmission Type | Gearshift |
| Number of gears | 6 |
| Cylinders | 3 |
| Strokes | 4-Stroke |
| Valves per cylinder | 4 |
| Valves | DOHC |
| Cooling | liquid |
| Displacement | 798 ccm |
Suspension Front
| Front suspension | Upside-Down telescopic fork |
|---|---|
| Technology | Big Piston |
| Brand | Showa |
| Diameter | 41 mm |
| Travel | 120 mm |
| Adjustment | Compression, Rebound |
Suspension Rear
| Suspension | Swing arm |
|---|---|
| Shock absorber | Monoshock |
| Brand | Showa |
| Travel | 130 mm |
| Adjustment | Preload, Rebound |
| Material | Steel |
Chassis
| Frame | Steel |
|---|---|
| Frame type | Tubular, Perimeter |
| Rake | 24.5 degree |
| Trail | 108 mm |
Brakes Front
| Type | Double disk |
|---|---|
| Diameter | 310 mm |
| Piston | Four pistons |
| Actuation | Hydraulic |
| Technology | radial |
Brakes Rear
| Type | Disc |
|---|---|
| Diameter | 220 mm |
| Piston | Single piston |
Assistance Systems
| Advanced Rider Assistance Systems | ABS, Cornering ABS, Quickshifter, Shift assistant with blipper, Cruise control, Traction control, , , |
|---|
Dimensions and Weights
| Front tyre width | 120 mm |
|---|---|
| Front tyre height | 70 % |
| Front tyre diameter | 17 inch |
| Rear tyre width | 180 mm |
| Rear tyre height | 55 % |
| Rear tyre diameter | 17 inch |
| Length | 2024 mm |
| Width | 815 mm |
| Height | 1088 mm |
| Wheelbase | 1402 mm |
| Seat Height | 810 mm |
| Kerb Weight (with ABS) | 198 kg |
| Fuel Tank Capacity | 14 l |
| License compliancy | A |
| Range | 297 km |
| Combined CO2 emissions | 109 g/km |
| Combined fuel consumption | 4.7 l/100km |
| Euro Norm | Euro 5+ |
| Maintenance interval | 16000 km |
Equipment
| Equipment | Connectivity, LED-Headlights, TFT display, , |
|---|
