Adly ATV 50 2015 vs. Aeon Cobra 50 2015

Technical Specifications Adly ATV 50 2015 compared to Aeon Cobra 50 2015

Adly ATV 50 2015

Aeon Cobra 50 2015

Show all

Same only

Differences

Adly ATV 50 2015

Aeon Cobra 50 2015

Engine and Drive Train

Bore	Bore	40 mm	Bore	40 mm
Stroke	Stroke	39.2 mm	Stroke	39.2 mm
Engine power	Engine power	3.8 HP	Engine power	3.1 HP
Rpm at Max. Power	Rpm at Max. Power	7,500 rpm	Rpm at Max. Power	5,800 rpm
Torque	Torque	3.4 Nm	Torque	3.7 Nm
Rpm at Torque	Rpm at Torque	7,250 rpm	Rpm at Torque	5,724 rpm
Compression Ratio	Compression Ratio	7	Compression Ratio	7.6
Cylinders	Cylinders	1	Cylinders	1
Strokes	Strokes	2-Stroke	Strokes	2-Stroke
Displacement	Displacement	49.3 ccm	Displacement	49.3 ccm

Brakes Front

Type	Type	Drum	Type	Drum

Brakes Rear

Type	Type	Drum	Type	Disc

Dimensions and Weights

Front tyre width	Front tyre width	19 mm	Front tyre width	20 mm
Front tyre height	Front tyre height	7 %	Front tyre height	7 %
Rear tyre width	Rear tyre width	19 mm	Rear tyre width	19 mm
Rear tyre height	Rear tyre height	7 %	Rear tyre height	95 %
Length	Length	1,350 mm	Length	1,676 mm
Width	Width	845 mm	Width	962 mm
Height	Height	835 mm	Height	1,007 mm
Wheelbase	Wheelbase	960 mm	Wheelbase	1,051 mm
Seat Height	Seat Height	700 mm	Seat Height	800 mm
Dry Weight	Dry Weight	103 kg	Dry Weight	129 kg
Fuel Tank Capacity	Fuel Tank Capacity	6 l	Fuel Tank Capacity	5 l
License compliancy	License compliancy	B	License compliancy	B
