KTM 500 EXC-F SIX DAYS 2026 vs. KTM 500 EXC-F SIX DAYS 2027

Technical Specifications KTM 500 EXC-F SIX DAYS 2026 compared to KTM 500 EXC-F SIX DAYS 2027

KTM 500 EXC-F SIX DAYS 2026

KTM 500 EXC-F SIX DAYS 2027

Show all

Same only

Differences

KTM 500 EXC-F SIX DAYS 2026

KTM 500 EXC-F SIX DAYS 2027

Engine and Drive Train

Fuel system	Fuel system	Injection	Fuel system	Injection
Throttle Bore	Throttle Bore	42 mm	Throttle Bore	42 mm
Clutch Type	Clutch Type	Multiplate in oil-bath	Clutch Type	Multiplate in oil-bath
Transmission	Transmission	Chain	Transmission	Chain
Transmission Type	Transmission Type	Gearshift	Transmission Type	Gearshift
Number of gears	Number of gears	6	Number of gears	6
Cylinders	Cylinders	1	Cylinders	1
Strokes	Strokes	4-Stroke	Strokes	4-Stroke
Displacement	Displacement	510.9 ccm	Displacement	510.9 ccm

Brakes Rear

Type	Type	Disc	Type	Disc

Suspension Front

Front suspension	Front suspension	Upside-Down telescopic fork	Front suspension	Upside-Down telescopic fork
Brand	Brand	WP	Brand	WP
Diameter	Diameter	48 mm	Diameter	48 mm
Travel	Travel	300 mm	Travel	300 mm
Adjustment	Adjustment	Compression, Rebound	Adjustment	Rebound

Suspension Rear

Brand	Brand	WP	Brand	WP
Travel	Travel	310 mm	Travel	310 mm
Adjustment	Adjustment	Compression, Rebound	Adjustment	Compression, Preload, Rebound
Material	Material	Aluminium	Material	Aluminium

Chassis

Frame	Frame	Chromium-molybdenum	Frame	Steel
Frame type	Frame type	Double cradle, Central tube	Frame type	Double cradle, Central tube

Brakes Front

Actuation	Actuation	Hydraulic	Actuation	Hydraulic

Dimensions and Weights

Seat Height	Seat Height	963 mm	Seat Height	963 mm
Fuel Tank Capacity	Fuel Tank Capacity	8.5 l	Fuel Tank Capacity	8.5 l
Ground clearance	Ground clearance	347 mm	Ground clearance	347 mm
