Harley-Davidson Sportster XL 883 N Iron 2010 vs. Harley-Davidson Sportster XL 883 R Roadster 2012

Technical Specifications Harley-Davidson Sportster XL 883 N Iron 2010 compared to Harley-Davidson Sportster XL 883 R Roadster 2012

Harley-Davidson Sportster XL 883 N Iron 2010

Harley-Davidson Sportster XL 883 R Roadster 2012

Show all

Same only

Differences

Harley-Davidson Sportster XL 883 N Iron 2010

Harley-Davidson Sportster XL 883 R Roadster 2012

Engine and Drive Train

Bore	Bore	76.2 mm	Bore	76.2 mm
Stroke	Stroke	96.8 mm	Stroke	96.8 mm
Rpm at Max. Power	Rpm at Max. Power	3,750 rpm	Rpm at Max. Power	3,750 rpm
Torque	Torque	70 Nm	Torque	70 Nm
Compression Ratio	Compression Ratio	8.9	Compression Ratio	8.9
Transmission	Transmission	Belt	Transmission	Belt
Cooling	Cooling	Air	Cooling	Air
Displacement	Displacement	883 ccm	Displacement	883 ccm

Brakes Front

Piston	Piston	Double piston	Piston	Double piston

Dimensions and Weights

Front tyre width	Front tyre width	100 mm	Front tyre width	100 mm
Front tyre height	Front tyre height	90 %	Front tyre height	90 %
Front tyre diameter	Front tyre diameter	19 inch	Front tyre diameter	19 inch
Rear tyre width	Rear tyre width	150 mm	Rear tyre width	150 mm
Rear tyre height	Rear tyre height	80 %	Rear tyre height	80 %
Rear tyre diameter	Rear tyre diameter	16 inch	Rear tyre diameter	16 inch
Length	Length	2,245 mm	Length	2,245 mm
Wheelbase	Wheelbase	1,510 mm	Wheelbase	1,542 mm
Seat Height	Seat Height	735 mm	Seat Height	760 mm
Kerb Weight	Kerb Weight	260 kg	Kerb Weight	260 kg
Fuel Tank Capacity	Fuel Tank Capacity	13 l	Fuel Tank Capacity	12.5 l
